System Brief Introduction:
The wiped film short path distillation of LTPM is a process of separation, purification and concentration of natural products, which is characterized by the separation of chemicals at the level of molecular free short route, which is different from the principle of separation by difference of traditional boiling point.
As a professional manufacturer, we can offer turnkey solutions for molecular distillation units, including molecular units, vacuum pumps, chillers, heaters, and necessary feeding / receiving components.
Turnkey Solution for Stainless Steel Molecular Distillation | |
1 | Jacketed feeding vessel with sight glass |
2 | Feed pump for automatic and continuous feeding |
3 | Motor to drive rotation with mechanical sealing (Optional: Magnetic sealing) |
4 | Jacketed evaporator with internal condenser |
5 | Coils cold trap with sight glass |
6 | Dry ice cold trap with sight glass |
7 | Collection pump(Distillate)for automatic and continuous collection |
8 | Collection pump (Residue) for automatic and continuous collection |
9 | Full jacketed pipe (feeding and collection section) |
10 | Control cabinet |
11 | Heating circulator for feeding vessel and pipeline |
12 | Heating circulator for jacketed evaporator |
13 | Heating circulator for residue collection section |
14 | Heating & cooling Circulator for internal condenser and distillate collection section |
15 | Cooling circulator for cooling coils cold trap |
16 | Cooling circulator for dual-use cold trap |
17 | Rotary vane vacuum pump |
18 | Molecular pump (Optional: Diffusion Pump) |
