Name | Model |
FZG-8 | |
Inner Size(mm) | 1500*1060*1220mm |
Outter Size (mm) | 1924*1720*1513mm |
Tray Holder Layers | 5 |
Distance between layers | 122 |
Tray Size (mm) | 460*640*45mm |
Tray Quantity | 8pcs |
Inner pressure (MPa) | ＜0.4 |
Heating Temperature ℃ | 35-150 |
Vacuum Rate (MPa) | -0.1 |
Water Evaporation Rate (kg/h) | 14kg(under -0.1MPa and 110℃) 8kg (under -0.1MPa and 70℃) |
Vacuum Pump and Power | SK-2 2kw (without condenser) 3kw (with condenser) |
Machine Weight | 1000kg |
Scope of application:
The air circulating oven is a versatile drying equipment,it is suitable for heating,soliding and drying material and product in the field of pharmaceutics,chemical,foodstuff,light industry such as:raw material medicine,Chinese traditional medicine,power granule,crude drug,packing bottle,pigment,dyestuff,dehydration vegetable,foodstuff,plastic resin,Electrical component,coat,wool,salt,catalyzer etc.
Features:
Most hot air is circulated in the oven.The heat efficiency is high and the energy is saved.
It use the forced ventilating function,there are adjustable air distribution plates inside the oven,the materials can be dried uniformly.
The heating source might be steam,hot water,Electricality and far infrared,with a wide selection.
The machine is low in the noise.The operation is in balance.
